RRRAP Assist
RRRAP Assist provides significant time savings throughout the Road Restraint Design Process by automation of certain tasks which are required when populating the Web-RRRAP Tool and when creating Design Drawings based on the outputs from the RRRAP Assessment.
What is
RRRAP Assist
RRRAP Assist is an Add-on for AutoCad that automates the submission process to the RRRAP website. Upon generating the barrier output file RRRAP Assist can import the barrier into your drawing.
•
Supports The Road Restraint Risk Assessment Process (RRRAP).
Supports designers in assessing whether a Vehicle Restraint System (VRS) is required in accordance with CD 377.
Output .csv files ready for upload to web-RRRAP.
Import web-RRRAP output file to automatically create VRS.
One button press for Critical slope height location identification.
•
•
•
•
Earthworks:
Critical Slopes
The input must represent the vertical profile of the whole length of the section. RRRAP Assist allows the creation Earthworks outputs from 3D strings generated in seconds and can also quickly identify the locations of critical slope heights.
[
]
Automatically Output
VRS from design file:
[
Using the output file from the web-RRRAP, you can automatically create the VRS design using RRRAP Assist, which includes restraint system, set-back/offsets showing envelopes for both working-widths and vehicle Intrusion offsets where required into the drawing.
]
